| Place of Origin: | CHINA |
|---|---|
| Brand Name: | BJTUFF |
| Certification: | ISO9001:2015 |
| Model Number: | DF22-T10 |
| Minimum Order Quantity: | 20 Pieces |
| Price: | Negotiated |
| Packaging Details: | Plastic boxes and wooden cases |
| Delivery Time: | 5-8 work days |
| Supply Ability: | 10000 Pieces/30 days |
| Alloy Material: | Tungsten Carbide | Application: | Rotary Drilling Rig |
|---|---|---|---|
| Process: | Forging And Welding | Product Name: | Rock Drilling Teeth |
| Weight: | 1264g | Body Material: | 42CrMo |
| High Light: | piling foundation round shank chisel,hard rock round shank chisel,round body protection shank chisel |
||
Piling Foundation Hard Rock Series B47K22H Round Shank Chisel With Body Protection
Advantage
1. The carbide tip use the low-cobalt material, with bigger carbide tip, with stronger abrasion resistance.
2. Advanced processing, to guarantee the carbide tips high quality.
3. The carbide tip has well-distributed micro-particles, with super impact strength, it will make higher force intensity during the drilling, and reduce the risk of breaking or cracking the teeth.
4. The carbide tips of new design (unique mesh style outlook) have tower shape or step shape, which makes the bullet bits scatter out the rock pieces more smoothly, the efficiency can reduce 20%; comparing the traditional bullet bit, the drilling efficiency of the new one can increase 33%. It can better service for drilling weak weathering rock 60-70Mpa, hard rock 80-90Mpa, except 100Mpa.
5. Streamlined body design of new design teeth (unique mesh style outlook ) make the teeth have better rotation, less resistance.
Application
Suitable for medium and strong weathering soft geology.and used widely which is the most cost-effective. and different alloy size by same hard rock series for different site condition .and you can contact us first to match the most suitable bullet teeth for yor site condition.
Items
| Type | Specification | Size(mm) |
| 3050-22 | 3050 | 22*27 |
| K60-N11 | 3060 | 25*30 |
| K59-T10 | 3060 | 22*27 |
| K60-T10 | 3060 | 25*30 |
| DF22 | 3055 | 22*27 |
| DF24 | 3055 | 24*33 |
| DF26 | 3060 | 26*34 |
| DF28 | 3060 | 28*36 |
| DF30 | 3060 | 30*36 |
| DF22-T10 | 3055 | 22*27 |
| DF24-T10 | 3055 | 24*33 |
| DF26-T10 | 3060 | 26*34 |
| DF28-T10 | 3060 | 28*36 |
| DF30-T10 | 3060 | 30*36 |
Holder Size
70 Holder, 80 holder, 70 alloy round holder, 80 alloy round holder, square tooth holder.
Reason for choose us
1. Customized configuration products for targeted territories.
2. Sponsorship on factory tours.
3. Constant innovation on the new products.
4. One-Stop foundation equipment solution.
FAQ
Q: What is the advantages of our products?
We are Factory. We use super quality raw material, which makes the drilling tools more durable and our drilling tools with competitive
price. and also we have the professional technical terms ,and can provide the one -stop foudation equipment solution .No matter you are dealers or end user, you will get the biggest profit.
Q: What's the nature of your company?
We are Manufacturer. We have factories all over China, all products posted are produced by ourselves, so we can offer you competitive price while ensuring product quality.
Q: Does this product support customization?
Yes, due to the fact that we have our own factories, We can customize products per your request.
Q: How long is your delivery time?
Generally it is 5-10 days if the goods are in stock. Or it is 15-20 days if the goods are not in stock, it is according to quantity.
